-26

. 6.
Fig. 6. ELEVATOR TRIM TAB CONTROL WHEEL ON CONTROL PEDESTAL



.
Figure and item No.

Part number

Nomenclatu re
1234567
K-o

Units per Assy
Effectivity
  26-5103-0
Fig. 6. ELEVATOR TRIM TAB CONTROL WHEEL ON CONTROL PEDESTAL
I
6 - 1 24-5103-100 .
Control wheel, assy
2
2 24-5103-70 .
Indicator pointer, assy
I
3 24-5103-80 .
Indicator pointer, assy
I
4 24-5103-31-4 .
Cable, assy
I
5 24-5103-31-3 .
Cable, assy
I
6 24-5103-35 .
Shaft , assy
I
7 26-5103-160-1 . ,
Support bracket with inscription plate aasy, right
I
8 24-5103-60-1 ..
Bracket, asay
I
9 26-5103-121 .. ,
Inscription plate, right
I
10 3166A-3-6 .. Screw 2
11 26-5103-160-2 . ,
Support bracket with inscription plate asay, left
I
12 24-5103-60-2 ...
Bracket, assy
I
13 26-5103-120 ..
Inscription plate, left
I
6 - 14 3166-3-6 ..
Screw
2
15 24-5103-61 .
Bolt
2
16 24-5103-62 .
Spring
2
17 24-5103-32 .
Cable drum
I
18 24-5103-4 .
Plug
2
19 24-5103-126 .
Disk
2
20 240C50-6 .
Coupling
2
21 5004-5-40 .
Bolt
I
22 3003-5-20 .
Bolt
4
23 3166-4-8 .
Screw
4
24 3373-5 .
Nut
5
25 3373-8 .
Nut
2
26 258-176 .
Limiter abaft
2
27 3401-0,8-5-10 .
Washer
8
28 127450-2-5-27 .
Saddle wasber
2
29 3402-2-8-20 .
Washer
2
30 3402-1-18-25 .
Washer
2
31 3402-0,5-5-10 .
Washer
I
6 - 32 3402A-1-5-10 .
Waaher

33 3402A-2-5-10 .
Washer

34 1,5x12-002
397-66
.
Cotter
4
